Sigma 32A 7KW EVSE GB\/T Chinese Electric Car EV Charger Portable Charging Station with Red CEE

Product Model: SGEN-EV16-008 SGEN-EV32-008 SGEN-EV16-T-008 SGEN-EV32-T-008
Plug Standard: Type2 / Type 1 Type2 / Type 1 Type 2 Type2
Rated Current: 16A 1P /16A 32A 1P /32A 16A 3P 32A 3P
Patch life: ≥ 10000 times ≥ 10000 times ≥ 10000 times ≥ 10000 times
Protection Level: IP65 IP65 IP65 IP65
Operation Voltage: 200V~250V 200V~250V 380V~450V 380V~450V
Certification: TUV CE TUV CE TUV CE TUV CE
Standard: IEC 61851 IEC 61851 IEC 61851 IEC 61851
Cable Specification: 3*2.5mm²+2*0.5mm² 3*2.5mm²+2*0.5mm² 5*2.5mm²+2*0.5mm² 5*6mm²+2*0.5mm²
Operating Temperature: -30℃ to +65℃
Function Option: Residential Use: 1.Standard type: RFID Card 2.Upgrade type: RFID Card ,WIFI&APP Support only for Android
Dimensions: 370mm (L) * 245mm (W) *130mm (H)
Control Box Function: 1.Over and under frequency protection 2.Over Current Protection 3.Type B Protection 4.Over Temperature Protection 5.Overload protection (self-checking recover) 6.Ground Protection 7.Over voltage and under-voltage protection 8.Lighting Protection
